Zenoah G320RC 31.8cc 4-Bolt Engine with Modified Shorty Clutch Housing for Losi Models

Description

G320RC 31.8cc 4-Bolt Engine – Complete with Clutch (Modified “Shorty” Clutch Housing) For Losi From Zenoah

Zenoah G320RC 31.8cc 4-Bolt Engine – Complete with Clutch

Brand new for 2014, the Zenoah G320RC 31.8cc 4-Bolt Engine. All new design – redesigned cylinder, crankcase, crankshaft, piston, etc for an absolute explosion of power, yet still in the same size package as the original Zenoah RC engines (G230RC, G240RC, G260RC, G270RC, G290RC)

This Zenoah G320RC engine has a 38mm bore, and 28mm stroke, for 31.8cc in its stock form. Includes a revolutionary new cylinder design with closed deck transfer ports (two piece), with removable covers.

The release of this Zenoah G320RC engine is the biggest news to hit the R/C engine world in years! We have been testing this engine for the last few months, and the power output is incredible.

This engine’s outer clutch housing is available in 2 versions. When ordering, select the clutch housing option you need from the drop-down menu.

bb125d – This version of the engine has a modified “shorty” clutch housing – For R/C cars that were originally designed specifically for CY engines, which have less total engine width. Fits Losi 5ive, Losi Desert Buggy XL (DBXL), and Redcat. A CY fan cover must also be used for this engine to fit a Losi/Redcat. This is the stock fan cover from your Losi/Redcat. We also have these fan covers available for purchase separately (see item eg411), also at the bottom of this page in the “related items”. DBXL Owners also need to use the CY Clutch plate and clutch plate bolt for clearance of the clutch bell and edge of the clutch

Note: Aftermarket Billet aluminum clutch housings are available for the Losi 5ive/DBXL & Redcat. (see part number sm106sv). If you plan on using one of these, purchase the bb125c and save yourself $5, as you won’t be using the stock clutch housing anyway. For those wanting an aftermarket clutch housing for HPI Baja, these are not yet available – but coming very, very soon 🙂

This engine is not compatible with most FG Modellsport or Smartech models. The larger crankcase interferes with the input shaft into the transmission.

What is the same as the existing Zenoah R/C engines:

• Pull Starter
• Fan Cover
• Ignition Coil
• Flywheel
• Inner Clutch Parts
• Spark Plug
• Carburetor Gasket
• Exhaust Gasket
• Muffler
• Air Filter
• Small Oil Seal

What is different:

• Cylinder
• Piston
• Piston Pin, Bearing, Washers
• Crankcase
• Crankshaft
• Crankcase Bearings
• Outer Clutch Case
• Engine Cover (shroud)
• Crankcase Gasket
• Insulator Gasket
• Cylinder Gasket
• Piston Pin, C-Clips, Washers, Bearing, etc
• Insulator Manifold
• Carburetor
• Large Oil Seal

Specifications:

• Displacement: 31.8cc
• Bore: 38mm
• Stroke: 28mm
• Dry Weight: 2.3kg
• HP: Approx 3.5 or more (before adding tuned exhaust). The G290RC is commonly listed at 3.5hp, but this engine puts out considerably more power than the G290RC. Adding a tuned exhaust or other modifications will further increase horsepower and torque numbers.
• Overall Dimension: 164mm Length, 215mm Width, 196mm height
• Fuel: Pre-mixed gasoline and 2-cycle oil, 25:1 ratio
• Fits most all the same applications as the regular Zenoah R/C Engines:
• HPI Baja 5B/5T/5SC, Losi 5ive, Losi Desert Buggy XL (DBXL), Redcat, Go-Ped(clutch driven versions only), Helicopter, and more!
• For Go-Ped use – This engine will bolt on and work on existing 54mm clutch models. Will work on spindle drive models only if ADA clutch is used (part gt201).
• This is a complete engine – including carburetor, air filter, clutch, and muffler.
• The crankshaft is a different style (larger) than the original zenoah engines, so the existing +2mm stroke crankshafts on the market will NOT be compatible. But, crankshafts compatible with this engine are in development, and will be available from DDM in the next few months. With a 2mm stroker crankshaft installed, this engine will become a Zenoah G340RC Engine (38mm bore, 30mm stroke, 34.02cc) performance beast!!!
• The exhaust port spacing is the same as the original engines, so all exhausts, tuned pipes, etc will remain compatible.
• The cylinder includes removable transfer port cover plates, these plates can easily be removed for easier access to the transfer ports.
