Description
LOGIQ ReadyAIR Load Leveling Air Suspension Kit – 2009-2014 Ford F-150
Upgrade your F-150 with LOGIQ’s ReadyAIR Load Leveling Air Suspension Kit—precision-engineered to replace factory coil springs and deliver unmatched ride quality, adjustability, and load stability. This complete, 100% factory-assembled system is designed for quick and easy installation with no guesswork.
Key Features:
-
Direct Coil Spring Replacement: Designed specifically for F-150 models equipped with factory coil springs
-
Primary Air Ride System: Offers superior ride comfort both loaded and unloaded
-
Height Adjustable: Easily adjust ride height from bump stop to lifted for improved clearance and control
-
Fits Multiple Configurations: Compatible with trucks from factory height up to 3” of lift; upgrade kits available for 3″–6″ lifted applications
-
Factory Air Replacement: Works as a direct swap for trucks with OEM air suspension—just add a 6mm to 1/4″ push-to-connect adapter (not included) if using the factory air system
-
Fully Assembled & Ready to Install: No complex setup or assembly required—get back on the road or trail faster
Whether you’re towing, hauling, or just cruising unloaded, the LOGIQ ReadyAIR system transforms your F-150’s ride and handling with the reliability and flexibility of cutting-edge air spring technology.
Specs
- Air Spring Location: Leaf Spring Mounted Outboard Frame Rails
- Air Spring Quantity: 2
- Load Capacity: 3,200 lbs @ 150 psi
- Maximum Pressure: 150 psi
- Minimum Pressure: 10 psi
Includes
- (1) Driver Side Air Spring Assembly
- (1) Passenger Side Air Spring Assembly
- (1) Hardware Kit
- (1) Manual Inflation Kit
- (1) Exhaust Heat Wrap Kit
Fitment
- 2009 Ford F150 (2 Wheel Drive & 4 Wheel Drive)
- 2010 Ford F150 (2 Wheel Drive & 4 Wheel Drive)
- 2011 Ford F150 (2 Wheel Drive & 4 Wheel Drive)
- 2012 Ford F150 (2 Wheel Drive & 4 Wheel Drive)
- 2013 Ford F150 (2 Wheel Drive & 4 Wheel Drive)
- 2014 Ford F150 (2 Wheel Drive & 4 Wheel Drive)
**Note
Not compatible with most aftermarket leaf springs. Not compatible with most 5th Wheel Hitches.
Instructions
Click Here for instructions
